About :

Typically, this box would measure around 4 inches in height, 4 inches in width, and 2 inches in depth, with a 1/2-inch conduit size. It's usually made from die-cast aluminum or a similarly durable material, ensuring resistance to corrosion and weather elements, making it suitable for outdoor use. Equipped with dual hubs, it likely has two threaded entries for conduit connections. These hubs are usually positioned on opposite ends of the box. It should offer versatile mounting options, either surface-mounted or flush-mounted, depending on the installation requirements. Look for certifications like UL (Underwriters Laboratories) or CSA (Canadian Standards Association) to ensure compliance with safety standards.

Also known as:

Single Gang Conduit Box,Surface-Mounted Single Gang Box, Single Gang Weatherproof Box,1-Gang Electrical Box.

Specification:

Material : Malleable iron
Standard Finish : Hot dip galvanized
UPC : 751338018112

Features:

• Suitable for use in concrete
• Tapered threaded hubs-NPT
• Internal grounding screw
• Suitable for wet locations when used with cover and neoprene gasket
